Gigabyte GC-TITAN RIDGE rev. 2.0 Thunderbolt 3 PCI-Ex4 add on Card USB Type-C DP

40 Gb/s Intel® Thunderbolt™ 3 Certified Add-in Card

The GC-TITAN RIDGE offers an easy way to upgrade GIGABYTE Thunderbolt™ ready motherboards with the new and faster Thunderbolt™ 3 connectivity without having to upgrade to a whole new system.



Port 1 : Support 5V/3A 9V/3A 15V/3A 20V/5A Power Delivery Spec

Port 2 : Support 5V/3A 9V/3A Power Delivery Spec

Dual Thunderbolt™ 3 – The fastest 40Gb/s single-wire connection

Delivers speeds of up to 40Gb/s-- that's 2 times faster than Thunderbolt™ 2 and 8 times faster than USB3. Thunderbolt™ 3 provides the fastest connection to any dock, display and device. A single port can daisy-chain up to 6 Thunderbolt devices without an additional hub or switch.





Daisy-chain Multiple Devices

Support for DisplayPort 1.4 makes Thunderbolt™ 3 a must have for any enthusiast. GIGABYTE GC-TITAN RIDGE support two displays in 4K* resolution at 60 FPS. In addition, Thunderbolt™ 3 over USB Type-C™ has revolutionary industry-first features such as Power Delivery 3.0, and the ability to daisy-chain up to 12 devices thanks to the dual USB Type-C™ ports.





* Depends on DisplayPort signal input from discrete display card.

Certified Motherboards with GC-TITAN RIDGE

* Supported status may vary depending on motherboard specifications.

* Support for Windows 10 64-bit with RS3 or later.

Series    Model

Z490 series

(Support by PCH PCIe x4 slot only)

Z490 AORUS MASTER / WATERFORCE



Z490 AORUS ULTRA



Z490 AORUS PRO AX



Z490 AORUS PRO



Z490 AORUS ELITE AC



Z490 AORUS ELITE



Z490I AORUS ULTRA



Z490 VISION G



Z490 GAMING X AX



 Z490 GAMING X



 Z490M GAMING X



 Z490 UD AC



Z490 UD



Z490M











H470 series

(Support by PCH PCIe x4 slot only)

H470 AORUS PRO AX



H470I AORUS PRO AX



H470 HD3



H470M DS3H



B460 series

(Support by PCH PCIe x4 slot only)

B460 AORUS PRO AC



B460 HD3



B460M AORUS PRO



B460M AORUS ELITE



B460M D3H



　



　



　



Z390 series

(Support by PCH PCIe x4 slot only)           Z390 AORUS MASTER     Z390 AORUS ULTRA         Z390 AORUS PRO WIFI   Z390 AORUS PRO

Z390 AORUS ELITE            Z390 GAMING X               Z390 UD               Z390 M GAMING

Z390 M

Z390 series

(Recommend to install on CPU PCIe x16 slot)      Z390 GAMING SLI

H370 series

(Support by BIOS F10 or after, PCH PCIe x4 slot only)       H370 AORUS GAMING 3 WIFI     H370 AORUS GAMING 3                H370 HD3

B360 series

(Support by BIOS F10 or after, PCH PCIe x4 slot only)       B360 AORUS GAMING 3 WIFI     B360 AORUS GAMING 3                B360 HD3P          B360 HD3

B360M D3P

Z370 series

(Support by BIOS F11 or after, PCH PCIe x4 slot only)       Z370 AORUS GAMING 7                Z370 AORUS GAMING 7-OP        Z370 AORUS GAMING 5          Z370 AORUS ULTRA GAMING WIFI 2.0

Z370 AORUS ULTRA GAMING WIFI           Z370 AORUS ULTRA GAMING WIFI-OP   Z370 AORUS ULTRA GAMING 2.0-OP      Z370 AORUS ULTRA GAMING 2.0

Z370 AORUS ULTRA GAMING     Z370 AORUS GAMING 3                Z370 AORUS GAMING K3             Z370 AORUS GAMING WIFI

Z370 UD3H          Z370XP SLI

X299X series

(Support by PCH PCIe x8_2 slot only)      X299X AORUS MASTER

X299 Workstation/Server series                X299-WU8

*Requires additional USB 3.0 19-pin female to USB 2.0 9-pin male cable for proper functioning (P/N: 12CR1-FUB001-01R)



AMD X570 series

(Recommend to install on PCH PCIe x4 slot)

(Recommend to update to latest BIOS version) X570 AORUS XTREME 1.1              X570 AORUS MASTER 1.1              X570 AORUS ULTRA 1.1            X570 AORUS PRO WIFI 1.1

X570 AORUS PRO 1.1
